Description
| Item | numerical aperture | Working distance (mm) | focal distance(mm) | resolution ratio(μm) | depth of focus
±Δp(μm) |
0bject Field (mm)
Φ24 Eyepiece |
1’’ Camera | Weight(g) |
| M PLAN APO 1X | 0.025 | 13 | 200 | 11.0 | 440 | 24 | 9.6×12.8 | 240 |
| M PLAN APO 2X | 0.055 | 34 | 100 | 5.0 | 91 | 12 | 4.8×6.4 | 206 |
| M PLAN APO 3.5X | 0.1 | 41 | 57.14 | 2.8 | 28 | 6.9 | 2.7×3.6 | 218 |
| M PLAN APO 5X | 0.14 | 35 | 40 | 2.0 | 14 | 4.8 | 1.92×2.56 | 212 |
| M PLAN APO 7.5X | 0.21 | 34 | 26.67 | 1.3 | 6.2 | 3.6 | 1.28×1.7 | 247 |
| M PLAN APO L 10X | 0.28 | 34 | 20 | 1.0 | 3.5 | 2.4 | 0.96×1.28 | 217 |
| M PLAN APO L 15X | 0.35 | 22 | 13.33 | 0.8 | 2.2 | 1.8 | 0.64×0.85 | 240 |
| M PLAN APO HL 20X | 0.42 | 20 | 10 | 0.7 | 1.6 | 1.2 | 0.48×0.64 | 271 |
| M PLAN APO HL 50X | 0.55 | 13 | 4 | 0.5 | 0.9 | 0.48 | 0.19×0.26 | 298 |
| M PLAN APO 100X | 0.7 | 6 | 2 | 0.4 | 0.56 | 0.24 | 0.1×0.13 | 260 |
