HT-80PS Stand Polarizing Microscope for Skin and Hair Analysis

HT-80PS Stand Polarizing Microscope for skin and hair analysis: 5.0MP, 1X–500X magnification, USB-powered, 8 LED lights, supports 2592×1944 video.

Key Features

Integrated 5.0MP CMOS sensor captures high-resolution images at 1X–500X magnification for detailed skin and hair structure analysis
Built-in 8 white-light LEDs with adjustable brightness (0–30000LUX) for consistent illumination across different sample types
USB connectivity enables direct use with PC (Windows XP to 10) and Android devices with OTG function
Supports multiple video resolutions up to 2592×1944 and frame rates from 15–30f/s for smooth real-time observation
Multilingual interface (Chinese, English, German, Russian, French, Japanese, Korean, Spanish, Italian) with OEM language expansion available

Model: HT-80PS Stand Polarizing Microscope
Controller: High Speed DSP (M-JPEG) with CMOS sensor
Magnification Range: 1X to 500X
Image Capture: SNAP Shot function for instant image saving
Sensor Resolution: 5.0MP (2592×1944 pixels)
Light Source: Built-in 8 white-light LEDs, adjustable from 0 to 30000LUX
Video Capture Resolutions: 320×240, 640×480, 800×600, 1024×768, 1280×960, 1600×1200, 2592×1944
Frame Rate: 15–30 frames per second under 500 LUX brightness
Focus Range: 0 to 4 cm
Connection: USB interface (5V DC power and data)
Supported Operating Systems: Windows XP/Vista/7/8/10, Android with OTG function
Software: HotViewer (PC), HotMicroscope (Android)
Language Support: Chinese, English, German, Russian, French, Japanese, Korean, Spanish, Italian (additional languages available via OEM)
Color: Gray (custom colors available via OEM)
Dimensions: 144 mm (L) × 37 mm (D)
Gross Weight: 500g

Model	HT-80PS
Magnification Range	1X – 500X
Sensor Resolution	5.0MP (2592×1944)
Video Resolutions	320×240, 640×480, 800×600, 1024×768, 1280×960, 1600×1200, 2592×1944
Frame Rate	15–30f/s
Light Source	8 White-light LEDs (0–30000LUX)
Focus Range	0–4cm
Power Supply	USB 5V DC
Connection	USB interface
Operating Systems	Windows XP to 10, Android (OTG)
Software	HotViewer (PC), HotMicroscope (Android)
Languages	Chinese, English, German, Russian, French, Japanese, Korean, Spanish, Italian
Color	Gray
Dimensions	144 mm (L) × 37 mm (D)
Gross Weight	500g

Clinical skin diagnostics requiring polarized light to visualize hair shafts and scalp conditions
Research labs analyzing hair fiber structure and skin surface morphology under polarizing illumination
Mobile inspection stations using Android phones via OTG for on-site skin and hair assessment
Training environments where multiple users need access to the same image data via PC software
